Xilix Multiple Hydrostatic Test Cells

Pressure Testing Systems

Why Are Xilix High-Pressure Hydrostatic Test Chambers Essential for Industrial Testing?

Hydrostatic testing ensures the safety, reliability, and compliance of high-pressure components across industries.

Xilix Systems designs and manufactures advanced hydrostatic test chambers for pipelines, valves, storage tanks, and industrial equipment.

This gallery features a custom multi-bay test cell, made in the USA. Built with a durable carbon steel frame, it spans 50 feet by 25 feet and includes three independent test bays.

With automation, wide pressure ranges, and reinforced safety, Xilix hydrostatic test chambers help businesses meet regulations, prevent failures, and improve efficiency.

Engineered for precision and durability, these chambers ensure accurate pressure evaluations while prioritizing safety and sustainability.

Key Features

What Are the Key Features of the Xilix Multiple High-Pressure Hydrostatic Test Chamber?

  • Multiple Hydrostatic Test Chamber Design – Engineered in modular 25-ft wide x 50-ft sections, with a 12-ft height, expandable. Configurable for three independent test zones, accommodating diverse materials. Vertical test chambers are available for specialized applications.
  • Extensive Pressure Range – Designed to withstand pressures from 1,000 PSI to 100,000 PSI, catering to a wide range of industrial testing applications.
  • Electric Actuated Part Supports – Ensures precise positioning and stabilization of test components for accurate and repeatable testing.
  • Advanced Safety Systems – Equipped with safety bumpers, light curtains, and beacon lights to minimize risks and enhance operational safety.
  • Integrated PTZ Cameras – Includes eight high-resolution cameras for real-time monitoring, documentation, and post-test analysis.
  • Automated Data Logging & Multi-Test Capability – Dual control panels and monitoring systems allow multiple simultaneous tests with automated tracking and analysis.
  • Closed-Loop Water System – An eco-friendly water reclamation, filtration, and reuse system that optimizes resource efficiency and lowers operational costs.

Benefits / Advantages

What Are the Key Benefits and Advantages of Xilix Hydrostatic Test Chambers?

  • Superior Safety Protection – Reinforced steel enclosures and automated safety interlocks minimize operator risks during high-pressure testing.
  • Regulatory Compliance Assurance – Built-in automated data logging provides traceable test records, ensuring compliance with industry safety standards.
  • High Precision & Accuracy – State-of-the-art pressure transducers and volume measurement systems deliver precise test results for critical components.
  • Modular & Scalable Design – Expandable chamber sizes allow industries to customize their test setup based on specific application requirements.
  • Cost-Effective & Sustainable – The closed-loop water filtration system reduces water waste, cutting operational costs while maintaining environmental responsibility.
  • Multi-Industry Compatibility – Used in industries such as oil & gas, medical, nuclear power, semiconductor, packaging, and more, making it highly versatile.
  • Seamless On-Site Installation – Xilix provides expert installation and system integration, ensuring a smooth setup for immediate operation.



Product Specifications

Test Pressures:

  • Standard Pressure Ranges: 1,000 PSI, 3,000 PSI, and 5,000 PSI
  • High-Pressure & Ultrahigh-Pressure: 10,000 PSI, 22,500 PSI, 30,000 PSI, up to 100,000 PSI

Testing Capabilities:

  • Leak Down Testing
  • Hydrostatic Testing
  • Drip Testing
  • Autofrettage
  • Burst Testing

Additional Features:

  • PTZ Camera System: Eight high-resolution cameras for internal monitoring and analysis
  • Chamber Structure: Reinforced carbon steel construction with scalable modular sections
  • Automation & Safety Controls: Dual control panels, real-time monitoring, and automated test cycle programming



Why Xilix Systems

Why Choose Xilix Systems for Your High-Pressure Hydrostatic Testing Needs?

  • Industry-Leading Engineering Expertise – With decades of experience, Xilix Systems specializes in designing and manufacturing high-performance hydrostatic test enclosures tailored to industrial needs.
  • Unmatched Customization & Scalability – Our modular designs allow for customizable chamber configurations to suit a wide range of pressure testing applications.
  • Global Reach & Proven Reliability – Xilix has delivered cutting-edge hydrostatic testing solutions for leading industries worldwide, ensuring precision, safety, and compliance.



Global Industry Applications

Xilix Systems has extensive experience across multiple industries, providing hydrostatic testing solutions for:
✔ Oil & Gas
✔ Food & Beverage
✔ Machine Tool Manufacturing
✔ Nanotechnology
✔ Nuclear Power
✔ Semiconductor Production
✔ Packaging
✔ Medical Device Manufacturing
